Fiber optics work better for sending digital signals which include audio, video and data information. These signals travel faster and farther without degradation over fiber optics.
It is optional and a rare instance when this is required. An HDMI source output connector provides 5V 55mA or greater power on the HDMI connector. Celerity TX draws power from this connection. However, in rare cases where insufficient power may be supplied, connecting the TX USB connector to a power source may be required.
The required specification is 5V 1000mA, 50/60Hz 120-240VAC. An example of this is the USB-AC adapter for the Apple iPhone.
No. Be sure to connect the Celerity RX USB 5V cable to a USB port that is labeled on the device as supplying 5V power. If a USB port is not marked in this manner, it may not supply continuous 5V power. Check the user manual of the device for further details.
HDMI input connectors on displays and projectors are not designed to support 5V power as HDMI output connectors on source components are. Therefore the power for Celerity RX must be supplied via USB 5V or, using a USB-AC adapter, a connection to AC power.
Celerity fiber optic cables utilize only glass fibers which cannot transfer power. The use of all glass fibers maximizes the picture quality and HDMI control signals and power provision via 5V source and 5V display USB provides the most reliable power.
The blue LED at the TX connector will be on when the connector is plugged into a powered source. The blue LED on the RX connector will turn on when both the HDMI and the USB are connected to a powered display. If the HDMI is not connected to a TV/projector/display port, the blue LED on the RX connector won't turn on.
Celerity recommends that our cables are connected directly between a source and display for best results. Celerity cannot guarantee the performance and specifications when a copper HDMI cable is used with Celerity fiber optic cables.
Celerity recommends that our cables are connected directly between a source and display for best results. Celerity cannot guarantee the performance and specifications when an HDMI adapter or coupler is used with Celerity fiber optic cables.
No. Interference from appliances, wireless devices, computers and other home and business electronics will not affect Celerity Fiber Optics. For professional installations, Celerity may be installed alongside other other cabling in riser, or plenum spaces and in wire raceways and wire trays.
Yes. They are actually quite strong. Inside the cable jacket is a woven layer of very strong yarn to provide durability and pulling strength. The yarn, known as "strength members", is made of aramid (commonly known as Kevlar) and protects the optical glass fibers. Pulling strength for Celerity fiber optic cables is 60 pounds.
The bend radius is 5mm (0.2") which is approximately the diameter of a pencil.
Yes. Connect an Apple USB-C to Digital AV Multiport Adapter to any of the Thunderbolt 3 ports on the MacBook Pro. Connect the Celerity HDMI cable (T) to the HDMI port on the adapter and connect the Celerity USB power cable to the USB port on the adapter.
